MESCIUS SPREAD for Windows Forms 17.0J
バージョン8.0Jで追加された機能

ここではバージョン 8.0Jで追加された機能を記載します。

【全般】

【数式】

【セル型】

【インポート、エクスポート】

バージョン 8.0J SP1の新機能

バージョン 8.0J SP2の新機能

バージョン 8.0J SP3の新機能

C#
コードのコピー
FarPoint.Win.Spread.Chart.SpreadChart chart1 = new FarPoint.Win.Spread.Chart.SpreadChart();

private void Form1_Load(object sender, EventArgs e)
{
    // テストデータの設定
    fpSpread1.ActiveSheet.SetArray(0, 0, new Object[,] { { null, "Q1", "Q2", "Q3", "Q4" } });
    fpSpread1.ActiveSheet.SetArray(1, 0, new Object[,] { { "S-1", 12, 14, 13, 15 } });
    fpSpread1.ActiveSheet.SetArray(2, 0, new Object[,] { { "S-2", 3, 1, 4, 2 } });
    fpSpread1.ActiveSheet.SetArray(3, 0, new Object[,] { { "S-3", 2, 5, 4, 3 } });
    fpSpread1.ActiveSheet.SetArray(4, 0, new Object[,] { { "S-4", 4, 1, 4, 2 } });

    // シリーズの設定(S-1)
    FarPoint.Win.Chart.LineSeries series1 = new FarPoint.Win.Chart.LineSeries();
    series1.SeriesNameDataSource = new FarPoint.Win.Spread.Chart.SeriesDataField(fpSpread1, "Values", "Sheet1!$A$2:$A$2", FarPoint.Win.Spread.Chart.SegmentDataType.Text);
    series1.Values.DataSource = new FarPoint.Win.Spread.Chart.SeriesDataField(fpSpread1, "Values", "Sheet1!$B$2:$E$2");
    series1.CategoryNames.DataSource = new FarPoint.Win.Spread.Chart.SeriesDataField(fpSpread1, "Values", "Sheet1!$B$1:$E$1", FarPoint.Win.Spread.Chart.SegmentDataType.Text);

    // シリーズの設定(S-2)
    FarPoint.Win.Chart.BarSeries series2 = new FarPoint.Win.Chart.BarSeries();
    series2.SeriesNameDataSource = new FarPoint.Win.Spread.Chart.SeriesDataField(fpSpread1, "Values", "Sheet1!$A$3:$A$3", FarPoint.Win.Spread.Chart.SegmentDataType.Text);
    series2.Values.DataSource = new FarPoint.Win.Spread.Chart.SeriesDataField(fpSpread1, "Values", "Sheet1!$B$3:$E$3");
    series2.CategoryNames.DataSource = new FarPoint.Win.Spread.Chart.SeriesDataField(fpSpread1, "Values", "Sheet1!$B$1:$E$1", FarPoint.Win.Spread.Chart.SegmentDataType.Text);

    FarPoint.Win.Chart.YPlotArea plotArea = new FarPoint.Win.Chart.YPlotArea();
    plotArea.Location = new PointF(0.2f, 0.2f);
    plotArea.Size = new SizeF(0.55f, 0.6f);

    // 折れ線の追加
    plotArea.Series.Add(series1);

    // 積み上げ縦棒の追加
    FarPoint.Win.Chart.StackedBarSeries sbar = new FarPoint.Win.Chart.StackedBarSeries();
    sbar.Series.Add(series2);
    plotArea.Series.Add(sbar);

    // 凡例の設定
    FarPoint.Win.Chart.LegendArea legend = new FarPoint.Win.Chart.LegendArea();
    legend.Location = new PointF(0.98f, 0.5f);
    legend.AlignmentX = 1f;
    legend.AlignmentY = 0.5f;

    // チャートモデルに各情報を追加
    FarPoint.Win.Chart.ChartModel model = new FarPoint.Win.Chart.ChartModel();
    model.LegendAreas.Add(legend);
    model.PlotAreas.Add(plotArea);

    // SPREADチャートにチャートモデルを設定
    chart1.ChartName = "barchart";
    chart1.Size = new Size(400, 200);
    chart1.Location = new Point(3, 130);
    chart1.Model = model;

    // シートにSPREADチャートを追加
    fpSpread1.Sheets[0].Charts.Add(chart1);

    // SeriesExpandedイベントの関連付け
    chart1.SeriesExpanded += Chart1_SeriesExpanded;
}

private void Chart1_SeriesExpanded(object sender, FarPoint.Win.Spread.Chart.ExpandSeriesEventArgs e)
{
    // 積み上げ縦棒の追加
    e.Series = new FarPoint.Win.Chart.StackedBarSeries();
    e.AppendOnExist = true;
}
Visual Basic
コードのコピー
Private WithEvents chart1 As New FarPoint.Win.Spread.Chart.SpreadChart()

Private Sub Form1_Load(sender As Object, e As EventArgs) Handles MyBase.Load
    ' テストデータの設定
    FpSpread1.ActiveSheet.SetArray(0, 0, New [Object](,) {{Nothing, "Q1", "Q2", "Q3", "Q4"}})
    FpSpread1.ActiveSheet.SetArray(1, 0, New [Object](,) {{"S-1", 12, 14, 13, 15}})
    FpSpread1.ActiveSheet.SetArray(2, 0, New [Object](,) {{"S-2", 3, 1, 4, 2}})
    FpSpread1.ActiveSheet.SetArray(3, 0, New [Object](,) {{"S-3", 2, 5, 4, 3}})
    FpSpread1.ActiveSheet.SetArray(4, 0, New [Object](,) {{"S-4", 4, 1, 4, 2}})

    ' シリーズの設定(S-1)
    Dim series1 As New FarPoint.Win.Chart.LineSeries()
    series1.SeriesNameDataSource = New FarPoint.Win.Spread.Chart.SeriesDataField(FpSpread1, "Values", "Sheet1!$A$2:$A$2", FarPoint.Win.Spread.Chart.SegmentDataType.Text)
    series1.Values.DataSource = New FarPoint.Win.Spread.Chart.SeriesDataField(FpSpread1, "Values", "Sheet1!$B$2:$E$2")
    series1.CategoryNames.DataSource = New FarPoint.Win.Spread.Chart.SeriesDataField(FpSpread1, "Values", "Sheet1!$B$1:$E$1", FarPoint.Win.Spread.Chart.SegmentDataType.Text)

    ' シリーズの設定(S-2)
    Dim series2 As New FarPoint.Win.Chart.BarSeries()
    series2.SeriesNameDataSource = New FarPoint.Win.Spread.Chart.SeriesDataField(FpSpread1, "Values", "Sheet1!$A$3:$A$3", FarPoint.Win.Spread.Chart.SegmentDataType.Text)
    series2.Values.DataSource = New FarPoint.Win.Spread.Chart.SeriesDataField(FpSpread1, "Values", "Sheet1!$B$3:$E$3")
    series2.CategoryNames.DataSource = New FarPoint.Win.Spread.Chart.SeriesDataField(FpSpread1, "Values", "Sheet1!$B$1:$E$1", FarPoint.Win.Spread.Chart.SegmentDataType.Text)

    Dim plotArea As New FarPoint.Win.Chart.YPlotArea()
    plotArea.Location = New PointF(0.2F, 0.2F)
    plotArea.Size = New SizeF(0.55F, 0.6F)

    ' 折れ線の追加
    plotArea.Series.Add(series1)

    ' 積み上げ縦棒の追加
    Dim sbar As New FarPoint.Win.Chart.StackedBarSeries()
    sbar.Series.Add(series2)
    plotArea.Series.Add(sbar)

    ' 凡例の設定
    Dim legend As New FarPoint.Win.Chart.LegendArea()
    legend.Location = New PointF(0.98F, 0.5F)
    legend.AlignmentX = 1.0F
    legend.AlignmentY = 0.5F

    ' チャートモデルに各情報を追加
    Dim model As New FarPoint.Win.Chart.ChartModel()
    model.LegendAreas.Add(legend)
    model.PlotAreas.Add(plotArea)

    ' SPREADチャートにチャートモデルを設定
    chart1.ChartName = "barchart"
    chart1.Size = New Size(400, 200)
    chart1.Location = New Point(3, 130)
    chart1.Model = model

    ' シートにSPREADチャートを追加
    FpSpread1.Sheets(0).Charts.Add(chart1)
End Sub

Private Sub chart1_SeriesExpanded(sender As Object, e As ExpandSeriesEventArgs) Handles chart1.SeriesExpanded
    ' 積み上げ縦棒の追加
    e.Series = New FarPoint.Win.Chart.StackedBarSeries()
    e.AppendOnExist = True
End Sub
